HERTZ Spl Show 1000W Mono Amplifier (Sp 1.900)

HERTZ Spl Show 1000W Mono Amplifier (Sp 1.900)

$799.99

HERTZ Spl Show 1000W Mono Amplifier (Sp 1.900)

$799.99

HERTZ Spl Show 1000W Mono Amplifier (Sp 1.900)

$799.99

SKU: SP1.900

$19 flat rate shipping. Delivered in 5 to 10 business days.
Please note: a $10 shipping surcharge applies to Western Australia orders.
Questions? Call 1300 856 888 to check availability or get expert help.
NEED PROFESSIONAL INSTALLATION?
  • Available at our Brookvale workshop
  • Expert 4WD technicians
Ask us for the fitting price and time
BOOK FITTING
SAFE CHECKOUT
Afterpay Google Pay Mastercard PayPal American Express Visa JCB Shop

SP 1.900 mono amplifier features Hertz ADC (Advanced D-Class) output stage, reaching up to 87% efficiency. The maximum power of 1000 W is already available at 2Ω and remains stable even at 1Ω. Being ultra-compact (211.6 x 130 x 49 / 8.3 x 5.1 x 1.9) with impressive power, SP 1.900 is the ideal choice for Motorcycle applications under-seat in sports cars and behind-seat installations in trucks.



Channels 1
Nominal power supply voltage 11 ÷ 15 VDC
Pulse Operating voltage 6 ÷ 16 VDC
Idling current 1.1 A
Idling current when off 0.03 mA
Consumption @ 14.4 VDC, MIN load impedance (Max Musical Power) 50 A
Remote IN 6 ÷ 15 VDC (9 mA)
DC-REM - Remote Turn on by SPK DC from OUTPUT BTL speakers 3.5 ÷ 7 VDC
Distortion - THD @ 1 kHz, 4Ω, 70% Rated Power 0.1%
Damping factor @ 1 kHz, 4Ω, 2 VRMS >300
Bandwidth @ -3 dB 5 Hz ÷ 500 Hz
S/N ratio (A weighted @ 1 V Input) 95 dBA
Pre-In sensitivity 0.6 ÷ 6 VRMS
Speaker-In sensitivity 2.2 ÷ 22 VRMS
Minimum load impedance: 1Ω
IP Rating IP55
Operating Temperature Range 0°C (32°F) to 55°C (131°F)
Weight (kg/lbs) 2.15 / 4.74
Adjustable Crossovers yes

Output Nominal Power (RMS) @ 14.4 VDC, THD 1%:
1 Ch: 600 W (4Ω)
1 Ch: 1000 W (2Ω)
1 Ch: 1000 W (1Ω)
Total Power 1000 W

INPUTS: Pre IN / Speaker IN
Full Yes
Lo-pass: 50 ÷ 250 Hz @ 24 dB/Oct.
Bass Boost 45Hz (adjustable) (0 ÷ 8) dB
Phase (adjustable) 0 ÷ 180°
Subsonic 25 Hz @ 24 dB/Oct.
Remote Volume Control (not included) -21 + 5 dB

SP 1.900
mm in
A 205 8.07
B 211.6 8.33
C 107 4.21
D 130 5.12
E 49 1.93
