HERTZ 24V Marine 1010W 5 Channel Amplifier (Venezia V5C 24V)

HERTZ 24V Marine 1010W 5 Channel Amplifier (Venezia V5C 24V)

$1,149.99

HERTZ 24V Marine 1010W 5 Channel Amplifier (Venezia V5C 24V)

$1,149.99
0 watching this item.

HERTZ 24V Marine 1010W 5 Channel Amplifier (Venezia V5C 24V)

$1,149.99

SKU: HMV5C24V

Available for enquiry only. For assistance, click Request Callback above or call us at 1300 856 888.
Product Details
Venezia V5C 24V is the compact five-channel marine amplifier, featuring 80 W x 4 (4Ω) plus 330 W (4Ω) for the subwoofer! Hertz Advanced Class D technology maximizes efficiency and power while minimizing heat and electromagnetic radiation - enhancing sound quality that reaches new highs with Hi-Res certification! High-powered channels with bridging capability deliver the output levels needed in the marine environment. Venezia V5C 24V is engineered and tested for marine applications (UV, salt-fog, vibrations, high/low temperature, thermal shock) and has obtained the IPX2 certification. The Safe-Lock Input, Output, and Power connections streamline installation and enhance durability in the field. The fanless convection cooling system is integrated into the cast heat-sink chassis. The balanced fully-differential input circuitry rejects electromagnetic noise and interference. The powerful and flexible preamp filter options are far beyond most mobile amplifier capabilities. Last but not least, Venezia V5C 24V is fully protected by short-circuit, overload, and thermal protections - with auto-resetting.

General Specs

Channels 5 - 3
POWER SUPPLY
Power supply voltage 22 ÷ 33 VDC
ldling current (power ON/OFF): 1.7 A / 0.05 mA
Consumption@ 1Ω, 14.4 VDC (Max Musical Power): 47 A
Remote In: 7 ÷ 15 VDC - 1 mA
AMPLIFIER STAGE
Distorsion - THD (100Hz @ 4Ω): <0,05%
Bandwidth: 10 ÷ 42 kHz
S/N Ratlo (A welghted @ 1 V): 100 dB
Damping factor (100Hz @ 4Ω) >130
Pre-ln sensitivity: 0.2 ÷ 5 VRMS
Pre-ln impedance: 10 kΩ
Load impedance (MIN)
@5Ch:
@3Ch:


4Ω + 4Ω + 2Ω
Weight (kg/lb): 3.72 / 8.2
Adjustable Crossovers yes

Output Power

OUTPUT POWER (RMS) @ 28.8 VDC, THD 1%
5Ch 80 W x 4 (4Ω) + 330 x 1 (4Ω)
5Ch 115 W x 4 (2Ω) + 550 W x 1 (2Ω)
3Ch 230 W x 2 (4Ω) + 330 W x 1 (4Ω)
3Ch 230 W x 2 (4Ω) + 550 W x 1 (2Ω)
Total Power 1010 W

INPUTS / FILTERS

lnputs: A Ch. Pre in
B Ch. Pre in
Sub Ch. Pre in
Pre Out: No
A Ch. filters: Yes
By-Pass Yes
Hi-Pass : 50 ÷ 500 Hz / 500 Hz ÷ 5 kHz @ 12 dB/Oct
B Ch. filters:
By-pass: Yes
Hi-Pass: 50 ÷ 500 Hz @ 12 dB/Oct
Band-Pass: 50 ÷ 500 Hz / 500 Hz ÷ 5 kHz @ 12 dB/Oct
Sub Ch. filters:
By-pass: No
Low-Pass: 50 ÷ 250 Hz @ 24 dB/Oct
Phase (adjust°): (0 ÷ 180°)
Subsonic: 25 Hz @ 24 dB/Oct
Boost 50 Hz (adjust): (0 ÷ 12) dB


Physical Specs

VENEZIA V5C 24V
mm in
A 270 10.6
B 240 9.44
C 185 7.2
D 155 6.1
E 54 2.12
kg lb
Weight: 3.72 8.2
