AUDISON Prima Line - 4" 2-Way 4 Ohm Coaxial Speakers - Pair (Apx 4)

AUDISON Prima Line - 4" 2-Way 4 Ohm Coaxial Speakers - Pair (Apx 4)

$229.99

AUDISON Prima Line - 4" 2-Way 4 Ohm Coaxial Speakers - Pair (Apx 4)

$229.99
0 watching this item.

AUDISON Prima Line - 4" 2-Way 4 Ohm Coaxial Speakers - Pair (Apx 4)

$229.99

SKU: APX4

Available for enquiry only. For assistance, click Request Callback above or call us at 1300 856 888.
Product Details
APX 4 features a concentric coaxial tweeter: with one single point of sound emission it is possible to obtain a consistent in-phase response, with consequent reconstruction of the acoustic scene comparable to a system of separate woofer + tweeter.The 4³ cones surround features the exclusive shallow Triple Wave profile, for maximum excursion linearity.

Technical Specs LF

Woofer Size 100 mm
Impedance 4 Ohm
Power Handling - Peak 120 W
Power Handling - Continuous 40 W
Sensitivity 91 dB
Frequency Response 80 ÷ 23k
Voice Coil Diameter 32 mm (0.59 in)
Magnet Size 75 x 40 x 10
Xmax 1.3 mm (1.26 in)

Technical Specs HF

Tweeter Size 24 mm (0.94 in)
Voice Coil Diameter 15 mm (0.59 in)

Electric-acoustic Specs

Re 3.1 Ohm
Fs 125 Hz
Mms 5.3 g (0.19 oz)
Cms 0.3
Bl 3.2
Qms 8
Qes 1,2
Qts 1
Vas 1.5 l (0.05 ft)
LE 0.04 mH

General

Weight 0.49 kg

Dimensions

APX 4
Dimension A 102 mm (4.02 in)
Dimension A3 130 mm
Dimension B 93 mm (3.66 in)
Dimension C 43 mm (1.69 in)
Dimension D 41 mm (1.61 in)
