Americas Garage 2" Levelling Kit with Fox 2.0" IFP Coilover suits Ford F-150 (21-25) by BDS Suspension BDS1913FSL

Americas Garage 2" Levelling Kit with Fox 2.0" IFP Coilover suits Ford F-150 (21-25) by BDS Suspension BDS1913FSL

$4,990.00

Americas Garage 2" Levelling Kit with Fox 2.0" IFP Coilover suits Ford F-150 (21-25) by BDS Suspension BDS1913FSL

$4,990.00

Americas Garage 2" Levelling Kit with Fox 2.0" IFP Coilover suits Ford F-150 (21-25) by BDS Suspension BDS1913FSL

$4,990.00

SKU: BDS1913FSL

$19 Flat Rate Shipping — Fast dispatch with 5–10 business days
Questions? Call 1300 856 888 to check availability or get expert help.
NEED PROFESSIONAL INSTALLATION?
  • Available at our Brookvale workshop
  • Expert 4WD technicians
  • LEARN MORE

SAFE CHECKOUT

Afterpay Google Pay Mastercard Paypal American Express Visa JCB Shop
Product Details

Take your F150 to the next level by installing a FOX 2.0 Snap Ring Strut 2 inch leveling kit with heavy duty upper control arms. These kits use the FOX 2.0 Performance Series coilover struts for a bolt-in upgrade to fit up to 35x12.50 tires while providing improved damper performance across all terrains. FOX 2.0 Struts These FOX 2.0 Performance Series coil-over struts bring impressive damper performance for great ride on and offroad capability designed as a direct bolt-in replacement for the factory strut assemblies while retaining the OE coil spring and top plate. They feature a 2.0" extruded and machined 6061 T6 aluminum body for better heat dispersion, along with an internal floating piston (IFP) to eliminate oil aeration, FOX's proprietary internals, 5/8" hard chrome plated heat-treated alloy shaft. HD Upper Control Arms (UCAs) Built for strength, performance and increased travel, these upper control arms are ready to bolt-in with most leveled/lifted trucks. They use 1.5" OD x .120-wall tubular construction with an indexed ball joint cup to correct the ball joint positioning allowing additional down travel and camber adjustment. At the frame mounting ends are durometer-specific rubber bushings for maintenance-free operation while at the other end a quality greaseable ball joints for smooth, quiet operation and superior durability. Arms are finished in a durable black powder coat with a billet aluminum dust cap ready for installation right out of the box.

  • Improved ride quality with FOX 2.0 coilovers
  • Heavy duty upper control arms for enhanced durability
  • Bolt-in installation for easy upgrades
  • Compatible with up to 35x12.50 tires
  • Designed for on and off-road performance
  • Durable black powder coat finish for longevity

Specifications

  • Front Lift Method : Coil-Over
  • Rear Lift Method : Stock
  • Shocks Included : Yes
  • Front Lift Height : 2"
  • Rear Lift Height : 0"

Features & Benefits

  • FOX Performance IFP shocks eliminates oil aeration allowing maximum performance from the factory-tuned, precision valving
  • HD Upper control arms provide superior strength and proper alignment
  • Adjustable height to fine tune
  • Provides level stance from front to rear
  • Easy, 100% Bolt On installation
  • FOX shocks are fully serviceable and resistant to corrosion and harsh environments.
  • Functions with Blue Cruise

Tyre & Wheel

Tyre & Wheel

  • 35 x 12.5 with 20 x 9 and 5.5 in. Backspace

Installation

Installation

Install Tools

  • Ball Joint Separation Tool
  • Strut Compressor

Important Notes

  • Works with bar pin lower strut mounts. For eye-style lower strut mounts use 2009-13 model kits.
  • Control arms with sensors are designed to keep the sensor arm in the stock position (the same position as the OE control arm).
  • Not designed to work with trucks with CCD.
  • Do NOT hit the aluminum knuckle on later model trucks with a hammer to separate the ball joint. Use the appropriate ball joint separation tool.
  • For replacement ball joints, use BDS081203. The ball joint is directional and must be installed with the dot facing either inward or outward on the vehicle, otherwise, damage may occur.
  • Special Service Tool 204-592 is recommended to dislodge the ball joint.

Components

Kit Components

  • BDS123262: Upper Control Arms, Suits 1-3,5-6" Lift, Set of 2
  • 985-02-146 (FOX98502146): Fox Performance Series 2.0" IFP Shock, 4.9", Suits 0-2" Lift, Single
  • 985-24-265 (FOX98524265): Fox Performance Series 2.0" IFP Shock 10.6", Suits 0- 1" Lift, Single
