AUDISON Prima Line - 10" 800W 4 + 4 Ohm Subwoofer (Aps 10 D)

AUDISON Prima Line - 10" 800W 4 + 4 Ohm Subwoofer (Aps 10 D)

$344.99

AUDISON Prima Line - 10" 800W 4 + 4 Ohm Subwoofer (Aps 10 D)

$344.99
0 watching this item.

AUDISON Prima Line - 10" 800W 4 + 4 Ohm Subwoofer (Aps 10 D)

$344.99

SKU: APS10D

Available for enquiry only. For assistance, click Request Callback above or call us at 1300 856 888.
Product Details
The APS 10 D is designed to deliver maximum performance in a sealed enclosure with ultra-compact volumes, from 10 lt. to 12 lt. The dual voice-coil and single voice coil versions feature push connectors for ease of wiring and configurations. Prima subwoofer components have been developed with a primary goal: to deliver high output in tight spaces. Output is a matter of excursion; the more air the cone moves, the more output. However reduced mounting depth traditionally has meant low excursion. Prima subwoofers employ a special cone-dustcap-basket geometry which guarantees large excursion of the mobile group, while keeping the mounting depth to a minimum. The surround and spider have been carefully designed to prevent the rocking-mode phenomenon. The cooling circuit has been designed with air vents on the basket underneath the spider, eliminating the need for vents on the bottom-plate. This allows the subwoofer to be mounted close to the back wall of the enclosure, making the most of the reduced mounting depth.

Technical Specs

Nominal diameter 250 mm (10 in)
Impedance 4+4 Ohm
Power Handling - Peak 800 W
Power Handling - Continuous 400 W
Sensitivity 84 dB
Voice Coil Ø 60 mm
Magnet Material HIGH DENSITY FLUX FERRITE
Magnet size D x d x h 140 x 70 x 30 mm
Cone Material WATER REPELLENT PRESSED PAPER
Xmax 12.6 mm (0.5 in)
Xmech 18 mm (0.71 in)
Driver Displacement Volume 1.12 l (0.04 ft)


Electric-acoustic Specs

Re 2.2 Ohm
Fs 27 Hz
Le 1.5 mH
Vas 41 l (1.448 ft)
Mms 170 g (5.997 oz)
Cms 0.2 mm/N
BL 10.4 T•m
Qts 0.52
Qes 0,58
Qms 4.7


General

Weight 5.24 kg


Dimensions

APS 10 D
Dimension A 270 mm (10.63 in)
Dimension B 233 mm (9.17 in)
Dimension C 105 mm (4.13 in)
Dimension D 88 mm (3.46 in)
Dimension C1 119 mm
