FOCAL Car Audio Speakers and Amplifiers

IW-IMP-EXT150 Impulse amp cable kit, facilitates quick install of Impulse amps to vehicles via ISO plugs Compatible with the IMPULSE 4.320 compact 4-channel digital amplifier, the IMP EXTENSION I/O 150 extension cables with Plug & Play connections offer total installation freedom as they can connect each amplifier channel to one of the speaker drivers. Input/output extension: ‘Input’ to send the audio signal from the main unit to the amplifier and ‘output’ to send the signal leaving the amplifier to the original audio system.    Developed with twisted cables to effectively eliminate disturbance Three different lengths to suit all vehicles Cut-resistant protective shield Great flexibility for the easiest possible installation Double In/Out connector to also receive the amplified signal from the IMPULSE 4.320 No soldering required Length: 5ft (1,50m)

FOCAL INSIDE NISSAN Y-ISO HARNESS HEAD UNIT ADAPTATION CABLE The Focal Inside NISSAN Y-ISO HARNESS head unit adaptation cable is designed for the IMPULSE 4.320 compact 4-channel digital amplifier. It allows the quick and simple connection of the Nissan original head unit and of Focal Inside extension cables. Designed specifically for your vehicle Quick and easy Plug and Play installation Direct link from the amplifier to your original head unit Connection to the extension cable via ISO connectors No soldering required Length: 0.9ft (0.3m)  Compatibility: for Nissan vehicles since 2008

FOCAL INSIDE FORD Y-ISO HARNESST-HARNESS ADAPTER FOR AN IMPULSE AMPLIFIER Inside upgrade harness Focal's Inside system upgrades include new aftermarket vehicle-specific speakers and subs, along with their Impulse 4.320 4-channel amp. Focal also offers a variety of cables and connectors that you'll need, including: speaker wire harnesses for tweeters, subs, and center channel; T-harnesses that connect the vehicle and factory radio to the upgrade system; and extension cables to connect the T-harness to the amplifier. This T-harness provides the upgrade connections between your select Ford vehicle and a Focal Impulse 4.320 amplifier by way of the appropriate extension cable (see below). Product highlights: Ford T-harness for a Focal Inside system upgrade provides connections for an Impulse 4.320 amplifier IMP EXT ISO 5' Extension Cable accessory power and ground connections available warranty: 1 year MFR # IW FORD Y-ISO Item # 091FORYISO  Features Overview: This vehicle specific harness simplifies adding the Focal Impulse 4.320 amplifier to a compatible vehicle. The ISO extension cable (item number 091IMPEXT1, sold separately) must also be added to connect the amp. This adapter supplies the amp with a speaker level signal input, power, and ground, and connects the amp's output to the factory speaker wiring. (Power and ground for the amp are connected using the attached crimp connectors.) Please enter your vehicle information to confirm compatibility. What's in the box: Focal Inside vehicle specific adapter harness

In order to feed your amplifiers with an appropriate and qualitative audio signal, keeping your original head-units and the associated OEM controls, you can choose the converter HILO.V3. HILO.V3 converts a stereo amplified signal in two low-level line outputs, eliminates parasitic interferences and generates separated grounds. You can now use an amplifier very simply, without any interference. It is now very easy to create a quality hi-fi install in your car. The selectable DC and AC voltages detection makes the HILO compatible with any original manufacturer head units. Entirely developed by Focal, HILO is available under generation 3 with an impedance simulator that creates a speaker simulation network to avoid head-unit muting.

Manufactured in France Focal is known for innovative design and accurate sound, and they continue their impressive record of revolutionary hi-fi car audio with the K2 Power M Series. These Focal FRAK 1-1/4" component tweeters are designed, engineered, and manufactured at Focal's facilities in France for true hi-fi sound in custom installations. These Focal FRAK component tweeters will faithfully reproduce the high-frequency detail and dynamics as part of a K2 Power M Series component system.     Astonishing detail Focal engineers applied some of their most innovative technologies, including an M-profile aluminum/magnesium cone, to make these tweeters uniquely equipped for high-performance playback. The shape and material help reduce harmonic distortion so you'll enjoy Focal's signature clean, unstressed, K2 sound. Focal also prioritizes shallow depth to make this special speaker a better fit for more installation locations. And with power handling up to 25 watts RMS, you can safely drive this speaker with a healthy amount of power. Product highlights: 1-1/4" tweeters aluminum 'M'-profile cone design tuned mass damper surround includes mounting brackets and grilles 4-ohm impedance handles up to 25 watts RMS (150 watts peak power) frequency response: 600-32,000 Hz sensitivity: 91 dB at 2.83 volts top-mount depth: 3/4" warranty: 1 year MFR # FRAK Item # 091FRAK Features & specs General Speaker Size 1 1/4 Design 1-way Tweeter Design M-Profile Cone Impedance (Ohms) 4 Tweeter Composition Aluminum Woofer Composition --- Woofer Surround Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) N/A Sensitivity at 2.83 volts 91 Frequency Response 600 - 32k Hz Minimum RMS Wattage --- Maximum RMS Wattage 25 Peak Power Handling (Watts) 150 Top-mount Depth (Inches) 0 3/4 Bottom-mount Depth (Inches) N/A Cutout Diameter or Length (inches) 2 Mounting Height (Inches) 0.5 Frame Width 2.3 Frame Length 2.3 What's in the box: 2 Tweeters Focal owner's manual 2 Steel mounting rings Quick start guide

Manufactured in France Focal is known for innovative design and accurate sound, and they continue their impressive record of revolutionary hi-fi car audio with the K2 Power M Series. The Focal 6.5KM 6-1/2" component woofers are designed, engineered, and manufactured at Focal's facilities in France for true hi-fi sound in custom installations. This pair of Focal 6.5KM component woofers will handle the low-end detail and dynamics in your K2 Power M Series component system.     Powerful sound Focal engineers applied some of their most innovative technologies, including an M-profile Aramid fiber cone, to make these 6-1/2" woofers uniquely equipped for high-performance playback. The shape and material help reduce harmonic distortion so you'll enjoy Focal's signature clean, unstressed, K2 sound. Focal also prioritizes shallow depth to make this special speaker a better fit for more installation locations. And with power handling up to 120 watts RMS, you can safely drive this speaker with a healthy amount of power. Product highlights: 6-1/2" component woofers (pair) "M"-profile Aramid fiber woofer cone tuned mass damper surround crossovers not included super-rigid aluminum basket neodymium magnet 4-ohm impedance handles up to 120 watts RMS (240 watts peak power) frequency response: 50-5,000 Hz sensitivity at 2.83V: 92.5 dB top-mount depth: 2-1/8" grille not included warranty: 1 year MFR # 6.5KM Item # 09165KM What's in the box: Two 6.5 KM Woofers Focal Performance owner's manual Eight 1-1/8" Screws Eight speed clips Quick start guide Features & specs General Speaker Size 6 1/2 Design 1-way Tweeter Design --- Impedance (Ohms) 4 Tweeter Composition --- Woofer Composition Aramid Fiber Woofer Surround Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) N/A Sensitivity at 2.83 volts 93 Frequency Response 50 - 5k Hz Minimum RMS Wattage --- Maximum RMS Wattage 120 Peak Power Handling (Watts) 240 Top-mount Depth (Inches) 2 3/16 Bottom-mount Depth (Inches) N/A Cutout Diameter or Length (inches) 5 5/8 Mounting Height (Inches) 0.45 Frame Width 6.494 Frame Length 6.494

Manufactured in France Focal is known for innovative design and accurate sound, and they continue their impressive record of revolutionary hi-fi car audio with the K2 Power M Series. This single Focal 3KM 3-1/8" midrange driver is designed, engineered, and manufactured at Focal's facilities in France for true hi-fi sound in custom installations. The Focal 3KM provides faultless mid-range performance as part of your K2 Power M Series component system.   Excellence in the midrange Focal engineers applied some of their most innovative technologies, including an M-profile Aramid fiber cone, to make this 3-1/8" driver uniquely equipped for high-performance playback. The shape and material help reduce harmonic distortion so you'll enjoy Focal's signature clean, unstressed, K2 sound. Focal also prioritizes shallow depth to make this special speaker a better fit for more installation locations. And with power handling up to 60 watts RMS, you can safely drive this speaker with a healthy amount of power. Product highlights: single 3-1/2" midrange speaker 'M'-profile Aramid fiber woofer cone tuned mass damper surround crossovers not included super-rigid aluminum basket 4-ohm impedance handles up to 60 watts RMS (120 watts peak power) frequency response: 200-9,000 Hz sensitivity: 89 dB at 2.83 volts top-mount depth: 1-1/8" optional grille available warranty: 1 year MFR # 3KM Item # 0913KM What's in the box: Focal 3KM owner's manual One 3 KM Midrange Four 3/4" Screws Four speed clips Quick start guide Features & specs General Speaker Size 3 Design 1-way Tweeter Design --- Impedance (Ohms) 4 Tweeter Composition --- Woofer Composition --- Woofer Surround Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) N/A Sensitivity at 2.83 volts 89 Frequency Response 200 - 9k Hz Minimum RMS Wattage --- Maximum RMS Wattage 60 Peak Power Handling (Watts) 120 Top-mount Depth (Inches) 1 1/8 Bottom-mount Depth (Inches) N/A Cutout Diameter or Length (inches) 2 5/8 Mounting Height (Inches) 0.176 Frame Width 3.144 Frame Length 3.144

About the Focal 25A4 Dream speakers Perfect sound. Discreet style. Premium construction. These are the standards that define Focal – and that make listening to Focal speakers an absolute pleasure. The Access line offers a marriage of performance and affordability, allowing you to experience the best in sound with a guilt-free conscience. Feel the bass Bass gives your music fullness and texture. If you shortchange the bass, you're not hearing your music the way it's meant to be heard. This Focal Access Series 25A4 subwoofer uses an all-weather DFS (dual fiberglass structure) cone to deliver that depth of character you may be missing from your system. The cone's butyl rubber surround helps to ensure excellent strength, durability, and musical accuracy. A unique ventilation system keeps the voice coil cool, allowing this sub to handle up to 200 watts RMS. Install this sub in a sealed box for tight, punchy bass, or in a ported enclosure for a little more boom. Highlights: 10" 4-ohm subwoofer dual fiberglass structure cone with butyl rubber surround 4-3/4" magnet promotes serious power handling spider decompression ventilated coil high SPL power handling: 50-200 watts RMS (400 watts peak) frequency response: 36-500 Hz top-mount depth: 5" sealed box volume: 0.52-0.88 cubic feet ported box volume: 0.71-1.23 cubic feet sensitivity: 85.4 dB at 2.83 volts grille not included warranty: 1 year MFR # 25A4 Item # 09125A4 What's in the box: One 10" Single voice coil woofer Manual Removable rubber mounting ring (installed) Eight 7/8" Self-tapping screws User manual (English/ French/ Russian) Focal window sticker

Same great bass in less space Focal's SUB 25 KXS subwoofer combines the great features of their K2 Power Series subs with a practical shallow-mount design to deliver the solid, hard-hitting low end you expect from Focal. Precision engineering and handmade craftsmanship ensure you'll enjoy great sound. Assembled and inspected by hand Focal assembles its subs by hand in their French facilities and rigorously inspects each one for any flaws to ensure your investment performs to the highest sonic standards. Mount this 4-ohm sub in a sealed enclosure to produce bass that's highly accurate and plenty forceful, then feed it up to 350 watts RMS without fear. A powerful magnet drives the sound A neodymium magnet supplies the backbone for the sub's powerful output, driving the motor assembly with unerring precision. Focal anchors the K2 Power sub with an aluminum basket that combines rigidity and efficient heat dissipation for reduced distortion and longer speaker life. 4-layer cone delivers sonic fidelity Focal's proprietary K2 4-layer aramid fiber composite sandwich cone combines rigidity and responsiveness to deliver sonic fidelity and high power handling. A butyl rubber surround maintains control of the cone, even during deep excursion. Subwoofer Wiring Diagrams Product highlights: 10" 4-ohm shallow-mount subwoofer 4-layer K2 composite sandwich cone with butyl rubber surround aluminum basket power handling: 350 watts RMS (700 watts peak) frequency response: 25-500 Hz sensitivity: 84.5 dB top mount depth: 3.72" sealed box volume: 0.45-0.85 cu. ft. grille not included warranty: 1 year MFR # SUB25KXS Item # 091SUB25KS What's in the box: One 10" Subwoofer Focal owner's manual Quick start guide Focal window sticker Features & specs Features and Specs Size 10 -inch Impedance (Ohms) 4 Cone Material K2 Aramid Fiber Sandwich Surround Material Butyl Rubber Port diameter (inches) N/A Port length (inches) N/A Free-Air No Dual Voice Coil No Sensitivity 84.5 dB at 2.83 volts Frequency Response 25 - 500 Hz Max RMS Power Handling 350 Peak Power Handling (Watts) 700 Top Mount Depth (inches) 3 3/4 Bottom Mount Depth (inches) N/A Cutout Diameter or Length (inches) 9 1/4 Frame Width 10.55 Frame Length 10.55 Vas (liters) 18 Fs (Hz) 35 Qts 0.8 Xmax (millimeters) 0 Parts Warranty 1 Year Labor Warranty 1 Year Box Requirements Ideal Sealed Box Volume (cubic feet) N/A Minimum Sealed Box Volume (cubic feet) 0.45 Maximum Sealed Box Volume (cubic feet) 0.85 Ideal Ported Box Volume (cubic feet) N/A Minimum Ported Box Volume (cubic feet) N/A Maximum Ported Box Volume (cubic feet) N/A

High-performance sub This sub's name gets straight to the point — Focal's K2 Power Series SUB 25 KXE 10" subwoofer delivers powerful, hard-hitting low end that combines realistic reproduction and competition-level sound pressure. Precision engineering and hand-assembled construction make this sub a sound choice for a high-performance bass system. Assembled and inspected by hand You can feed the SUB 25 KXE subwoofer up to 600 watts RMS without fear. This dual 4-ohm voice coil sub works best in sealed enclosures to produce bass that's highly accurate and plenty forceful. Focal assembles its sub by hand in their French facilities and rigorously inspects each one for any flaws to ensure your investment performs to the highest sonic standards. A powerful magnet drives the sound A massive two-segment magnet supplies the backbone for the sub's powerful output, driving the motor assembly with unerring precision. Focal anchors the K2 Power sub with an aluminum basket that combines rigidity and efficient heat dissipation for reduced distortion and longer speaker life. 4-layer cone delivers sonic fidelity Focal's proprietary K2 4-layer aramid fiber composite sandwich cone combines rigidity and responsiveness to deliver sonic fidelity and high power handling. A butyl rubber surround maintains control of the cone, even during deep excursion. Subwoofer Wiring Diagrams Product highlights: 10" dual 4-ohm voice coil subwoofer 4-layer K2 composite sandwich cone with butyl rubber surround aluminum basket power handling: 600 watts RMS (1200 watts peak) frequency response: 25-500 Hz sensitivity: 84.5 dB top mount depth: 6.8" mounting height: 1.0" cutout diameter: 9.254 sealed box volume: 0.48 - 0.93 cu. ft. grille not included warranty: 1 year MFR # SUB25KXE Item # 091SUB25KX What's in the box: Focal owner's manual 10" Dual 4-ohm voice coil subwoofer Quick start guide (English/ French/ German/ Italian/ Spanish/ Portuguese/ Dutch/ Russian/ Polish/ Chinese/ Korean/ Japanese/ Arabic) Features & specs Features and Specs Size 10 -inch Impedance (Ohms) 2, 8 Cone Material K2 Aramid Fiber Sandwich Surround Material Butyl Rubber Port diameter (inches) N/A Port length (inches) N/A Free-Air No Dual Voice Coil Yes Sensitivity 84.5 dB at 2.83 volts Frequency Response 25 - 500 Hz Max RMS Power Handling 600 Peak Power Handling (Watts) 1200 Top Mount Depth (inches) 6 13/16 Bottom Mount Depth (inches) N/A Cutout Diameter or Length (inches) 9 5/16 Frame Width 10.55 Frame Length 10.55 Vas (liters) 20 Fs (Hz) 38 Qts 0.52 Xmax (millimeters) 22.5 Parts Warranty 1 Year Labor Warranty 1 Year Box Requirements Ideal Sealed Box Volume (cubic feet) N/A Minimum Sealed Box Volume (cubic feet) 0.48 Maximum Sealed Box Volume (cubic feet) 0.93 Ideal Ported Box Volume (cubic feet) N/A Minimum Ported Box Volume (cubic feet) N/A Maximum Ported Box Volume (cubic feet) N/A

12-INCH SLIM SUBWOOFER•  Flax Cone: High rigidity, deep and controlled bass•  Engraved serial number: Guarantee of authenticity•  Fiberglass voice-coil material: Overheating reduction•  Integrated magnet: Compact and powerful•  Push terminal block: Easy wiring•  Rubber surround catenary profile: Long life, reliability for a high excursionKEY POINTS•  Shallow and lightweight•  Mace in France in the Focal workshops•  Robust design and quality materials•  Exclusive Flax* technologySPECIFICATIONS:•  Diameter: 12″•  Cone: Sandwich Flax•  Magnet: Ferrite•  Surround: Rubber•  Max Power: 600W•  Nom Power: 300W RMS•  Sensitivity (2.83v/1m): 89dB

ISUB ACTIVE 2.1 2-channel amplifier The ISUB ACTIVE 2.1 subwoofer complements any original audio system, providing powerful (260 W), dynamic bass and amplification of the vehicle's front channels (2.1). It connects to the car radio's speaker outputs via the supplied Plug & Play cable, providing a genuine enhancement of the sound experience without loss of space in the cabin or trunk. KEY POINTS Focal know-how 2-channel amplifier Ready to use (Plug & Play ISO cable included) Compact product, discreet integration Ease of use Various settings (adjustable incoming signal, adjustable amplifier crossover, sound level boost, etc.) Robust design Sound - Acoustics Product type : Ultracompact amplified 20cm (8 ") and 2 -channel amplified subwoofer Loudspeakers : Subwoofer: 8" Filter : Integrated Frequency response (+/- 3dB) : 45Hz - 150kHz Maximum power : 260 watts Motor : Ferrite Nominal Impedance : 4 Ω Nominal power : 130 W RMS Sound - Electronics Number of channels : 2 Configurable High Pass / Low Pass filter : High-pass crossover ajustable from 20 to 50 Hz Low-pass crossover ajustable from 50 to 180 Hz RMS power : 130 W RMS

FOCAL INSIDE IC T3Y 1004" 2-WAY SPEAKERS Customized sound for your Tesla Audio upgrades for Tesla owners have so far been few and far between. But now the Inside Series brings Focal's famous sound to your electric vehicle. The best news of all is that Focal designs and builds these speakers to fit perfectly into Tesla Model 3 and Model Y vehicles. All the necessary mounting hardware is included, and integrated connectors connect to your existing factory speaker plugs — no cutting, splicing, or vehicle modifications required. The flax woofer cone stays light and stiff while maintaining a natural overall sound. What Focal is famous for Focal incorporates their innovative flax woofer cones into the Inside IC T3Y 100 4" 2-way speakers. Focal discovered that a flax woofer cone produces a dynamic sound that's worthy of its reputation. At half the weight of fiberglass, these flax fibers help create a very rigid yet lightweight cone that ensures accuracy and limits unwanted vibrations. You'll find another Focal innovation in these speakers: the inverted dome tweeter. In combination with the woofer, they achieve a clear, natural full-range sound that lets you hear your music the way it was meant to be heard. Installation Note: Unless you're powering these speakers with an amplifier that has an active high-pass crossover, the included in-line filter must be used between the crossover and woofer. Product highlights: 2-way speaker system designed to fit Tesla Model 3 and Model Y vehicles Tesla-specific wire connectors (no cutting required) 4" flax woofer with butyl rubber surround aluminum inverted dome tweeter impedance: 4 ohms power handling: 40 watts RMS (80 watts peak) frequency response: 150-20,000 Hz sensitivity: 88 dB grilles not included warranty: 1 year MFR # IC T3Y 100 Item # 091ICT3Y10  Features & specs General Speaker Size Vehicle-specific Design 2-way Tweeter Design Inverted Dome Impedance (Ohms) 4 Tweeter Composition Aluminum Woofer Composition Flax Woofer Surround Butyl Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) 84.07 Sensitivity at 2.83 volts 88 Frequency Response 150 - 20k Hz Minimum RMS Wattage --- Maximum RMS Wattage 40 Peak Power Handling (Watts) 80 Top-mount Depth (Inches) 1 3/8 Bottom-mount Depth (Inches) 1 11/16 Cutout Diameter or Length (inches) 3 5/8 Mounting Height (Inches) 0.3 Frame Width 4.015 Frame Length 4.015 What's in the box: Two 2-way speakers Six 5/8" Screws Quick start guide (English/ French/ German/ Italian/ Spanish/ Portugese/ Dutch/ Polish/ Russian/ Chinese/ Korean/ Japanese/ Arabic) Focal window sticker 2 Adhesive backed Focal Inside badges

Designed specifically for Mercedes-Benz vehicles, the high-fidelity surround coaxial kit ICR MBZ 100 is the perfect solution for car models that have dedicated space for surrounds. It installs easily and discreetly and provides high-quality sound rendering. The speaker drivers include the Flax sandwich cone, which is made in France, and which delivers natural midranges and ultra-real voices. To further optimise performance within very small spaces, this kit includes a neodymium motor. For an intense experience, combine this kit with ISUB MBZ 2 subwoofers that are fitted with Polyglass cones and fully compatible with the Focal Inside concept: 100% Plug & Play. KEY POINTS: Developed and made in France Quick and easy to install with no modifications to the vehicle required Seamless integration into the cabin High-fidelity sound and excellent power handling Advanced speaker driver protection Dedicated manufacturer Plug & Play connector More Information More Information Speaker Type Co-axial Speaker Setup 2-Way Woofer Diameter (mm) 100mm Woofer Diameter (Inch) 4 Inch Mounting Diameter 102mm Woofer Mounting Depth 34.2mm RMS Power 40W Impedance 4 Ohm Grilles Included Not included Sensitivity (dB) 88dB Frequency Response 150Hz - 20kHz

FOCAL ACX 690AUDITOR EVO SERIES 6"X9" 3-WAY CAR SPEAKERS The benefit of Focal innovation Focal designed their updated Auditor EVO Series speakers in France. That's a big deal — it means that these entry-level car speakers were reimagined by some of the same minds that design their flagship models. You'll recognize staples of Focal's famous sound: the inverted dome tweeter for precise treble and an improved soundstage; a polypropylene cone for a neutral and dynamic sound; and a butyl surround for impressive responsiveness. The aim of Auditor EVO Focal's goal is to improve the audio experience in any type of car, and these impressive ACX 690 6"x9" 3-way speakers will easily outperform your factory speakers and bring the fun back to your drive time. Prepare for a new level of richness in the midrange, and Focal's acclaimed inverted dome tweeter and supertweeter, with its handsome black lacquered finish, broadcast high-frequency details that put standard tweeter designs to shame. An integrated, high-fidelity crossover ensures that the woofer handles only the lower frequencies and the tweeter only handles the highs, giving you a smooth sound overall. Ready to ride A polypropylene woofer cone and butyl rubber surround help these speakers live a long life in your car doors, withstanding all kinds of environmental abuse while delivering robust sound. Product highlights: 3-way car speakers (pair) 6"x9" polypropylene woofer cone with butyl rubber surround Mylar inverted dome tweeter and supertweeter rigid steel basket mesh/ABS mesh grilles included handles up to 80 watts RMS (160 watts peak) frequency response: 50-20,000 Hz sensitivity: 92 dB impedance: 4 ohms mounting depth: 3-3/16" warranty: 1 year MFR # ACX690 Item # 091ACX690  Features & specs General Speaker Size 6X9 Design 3-way Tweeter Design Inverted Dome Impedance (Ohms) 4 Tweeter Composition Mylar Woofer Composition Polypropylene Woofer Surround Butyl Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) N/A Sensitivity at 2.83 volts 92 Frequency Response 50 - 20k Hz Minimum RMS Wattage --- Maximum RMS Wattage 80 Peak Power Handling (Watts) 160 Top-mount Depth (Inches) 3 3/16 Bottom-mount Depth (Inches) 3 5/8 Cutout Diameter or Length (inches) 0 Mounting Height (Inches) 0.625 Frame Width 6.524 Frame Length 9.237 What's in the box: Two 3-way speakers Focal owner's manual 2 Grilles 2 Grille mounting rings Eight 1-3/8" Screws 8 Speed clips Owner's manual (English/ French/ German/ Spanish/ Italian/ Portuguese/ Dutch/ Polish/ Chinese/ Russian/ Korean/ Japanese/ Arabic)

FOCAL ACX 165 AUDITOR EVO 6-1/2"" 2-WAY CAR SPEAKERS The benefit of Focal innovation Focal designed their updated Auditor EVO Series speakers in France. That's a big deal — it means that these entry-level car speakers were reimagined by some of the same minds that design their flagship models. You'll recognize staples of Focal's famous sound: the inverted dome tweeter for precise treble and an improved soundstage; a polypropylene cone for a neutral and dynamic sound; and a butyl surround for impressive responsiveness. The aim of Auditor EVO Focal's goal is to improve the audio experience in any type of car, and these impressive ACX 165 6-1/2" coaxial speakers will easily outperform your factory speakers and bring the fun back to your drive time. Prepare for a new level of richness in the midrange, and Focal's acclaimed inverted dome tweeter, with its handsome black lacquered finish, broadcasts high-frequency details that put standard tweeter designs to shame. An integrated, high-fidelity crossover ensures that the woofer handles only the lower frequencies and the tweeter only handles the highs, giving you a smooth sound overall. Ready to ride A polypropylene woofer cone and butyl rubber surround help these speakers live a long life in your car doors, withstanding all kinds of environmental abuse while delivering robust sound. Product highlights: 2-way car speakers (pair) 6-1/2" polypropylene woofer cone with butyl rubber surround Mylar inverted dome tweeter rigid steel basket mesh/ABS mesh grilles included handles up to 60 watts RMS (120 watts peak) frequency response: 60-21,000 Hz sensitivity: 91.5 dB impedance: 4 ohms mounting depth: 2-1/2" warranty: 1 year MFR # ACX165 Item # 091ACX165 Features & specs General Speaker Size 6 1/2 Design 2-way Tweeter Design Inverted Dome Impedance (Ohms) 4 Tweeter Composition Mylar Woofer Composition Polypropylene Woofer Surround Butyl Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) N/A Sensitivity at 2.83 volts 91.5 Frequency Response 60 - 21k Hz Minimum RMS Wattage --- Maximum RMS Wattage 60 Peak Power Handling (Watts) 120 Top-mount Depth (Inches) 2 1/2 Bottom-mount Depth (Inches) 2 11/16 Cutout Diameter or Length (inches) 5 11/16 Mounting Height (Inches) 0.23 Frame Width 6.595 Frame Length 6.595 What's in the box: Two 2-way speakers Focal owner's manual 2 Grilles 2 Grille mounting rings Eight 1-3/8" Screws 8 Speed clips Owner's manual (English/ French/ German/ Spanish/ Italian/ Portuguese/ Dutch/ Polish/ Chinese/ Russian/ Korean/ Japanese/ Arabic)

FOCAL INSIDE IS T3Y 1004" COMPONENT SPEAKER SYSTEM Customized component sound for your Tesla Audio upgrades for Tesla owners have so far been few and far between. But now the Inside Series brings Focal's famous sound to your electric vehicle. The best news of all is that Focal designs and builds these speakers to fit perfectly into Tesla Model 3 and Model Y vehicles. All the necessary mounting hardware is included, and integrated connectors connect to your existing factory speaker plugs — no cutting, splicing, or vehicle modifications required. The flax woofer cone stays light and stiff while maintaining a natural overall sound. Famous Focal sound Focal uses their flax woofer cones in their Inside IS T3Y 100 4" component speakers. Focal discovered that a flax woofer cone produces a dynamic sound that's worthy of its reputation. At half the weight of fiberglass, these flax fibers help create a very rigid yet lightweight cone that ensures accuracy and limits unwanted vibrations. You'll find another Focal innovation in these speakers: inverted dome tweeters. Combined with the system's premium inline crossovers, they produce clear, natural highs that let you hear your music the way it was meant to be heard. Installation Note: Unless you're powering these speakers with an amplifier that has an active high-pass crossover, the included in-line filter must be used between the crossover and woofer. Product highlights: component speaker system includes two woofers, two tweeters, two inline crossovers designed to fit Tesla Model 3 and Model Y vehicles Tesla-specific wire connectors (no cutting required) 4" flax woofer with butyl rubber surround aluminum inverted dome tweeter impedance: 4 ohms power handling: 50 watts RMS (100 watts peak) frequency response: 150-20,000 Hz sensitivity: 87 dB grilles not included warranty: 1 year MFR # IS T3Y 100 Item # 091IST3Y10  Features & specs General Speaker Size Vehicle-specific Design 2-way Tweeter Design 20mm Inverted Dome Impedance (Ohms) 4 Tweeter Composition Aluminum Woofer Composition Flax Woofer Surround Butyl Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) 83.15 Sensitivity at 2.83 volts 87 Frequency Response 150 - 20k Hz Minimum RMS Wattage --- Maximum RMS Wattage 50 Peak Power Handling (Watts) 100 Top-mount Depth (Inches) 1 3/8 Bottom-mount Depth (Inches) N/A Cutout Diameter or Length (inches) 3 5/8 Mounting Height (Inches) 0.28 Frame Width 4.02 Frame Length 4.02 What's in the box: Two midrange drivers Two tweeters (12" Wire attached with in-line crossover) Two in-line midrange crossovers Two 40" Tweeter extention wires Two 24" Midrange extention wires Two 24" Crossover input extention wires Quick start guide (English/ French/ German/ Italian/ Spanish/ Portugese/ Dutch/ Polish/ Russian/ Chinese/ Korean/ Japanese/ Arabic) Focal window sticker 2 Adhesive backed Focal Inside badges

FOCAL INSIDE ICC T3Y 1004" SPEAKER AND 1" TWEETER Customized sound for your Tesla Audio upgrades for Tesla owners have so far been few and far between. But now the Inside Series brings Focal's famous sound to your electric vehicle. The best news of all is that Focal designs and builds these speakers to fit perfectly into Tesla Model 3 and Model Y vehicles. All the necessary mounting hardware is included, and integrated connectors connect to your existing factory speaker plugs — no cutting, splicing, or vehicle modifications required. The flax woofer cone stays light and stiff while maintaining a natural overall sound. Famous Focal sound Focal incorporates their innovative flax woofer cones into the Inside ICC T3Y 100 4" center speaker. Focal discovered that a flax woofer cone produces a dynamic sound that's worthy of its reputation. At half the weight of fiberglass, these flax fibers help create a very rigid yet lightweight cone that ensures accuracy and limits unwanted vibrations. You'll find another Focal innovation in these speakers: an inverted dome tweeter. Combined with the woofer, it produces clear, natural highs that let you hear your music the way it was meant to be heard. Installation Note: Unless you're powering these speakers with an amplifier that has an active high-pass crossover, the included in-line filter must be used between the crossover and woofer. This system includes one woofer and one tweeter. Product highlights: 4" woofer and 1" tweeter for center dash location designed to fit Tesla Model 3 and Model Y vehicles Tesla-specific wire connectors (no cutting required) 4" flax woofer with butyl rubber surround aluminum inverted dome tweeter impedance: 4 ohms power handling: 50 watts RMS (100 watts peak) frequency response: 150-20,000 Hz sensitivity: 87 dB grilles not included warranty: 1 year MFR # ICC T3Y 100 Item # 091ICCT3Y1  Features & specs General Speaker Size Vehicle-specific Design 2-way Tweeter Design 20mm Inverted Dome Impedance (Ohms) 4 Tweeter Composition Aluminum Woofer Composition Flax Woofer Surround Butyl Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) 83.15 Sensitivity at 2.83 volts 87 Frequency Response 150 - 20k Hz Minimum RMS Wattage --- Maximum RMS Wattage 50 Peak Power Handling (Watts) 100 Top-mount Depth (Inches) 1 3/8 Bottom-mount Depth (Inches) N/A Cutout Diameter or Length (inches) 3 5/8 Mounting Height (Inches) 0.28 Frame Width 4.02 Frame Length 4.02 What's in the box: One center channel midrange One center channel tweeter 8" Wiring harness with in-line crossovers Two 5/8" Screws 2 Screw anchors Quick start guide (English/ French/ German/ Italian/ Spanish/ Portugese/ Dutch/ Polish/ Russian/ Chinese/ Korean/ Japanese/ Arabic) Focal window sticker 2 Adhesive backed Focal Inside badges

Sublime 3-way system Handmade in France, the Elite K2 Power Series ES 165 KX3E component system is the culmination of Focal's passion for perfect sound. Focal's sound gurus engaged in intensive listening sessions designing this line of speakers so that you enjoy uncanny realism, sweeping dynamics, and breathtaking depth in your music. This Focal system includes tweeters, midrange drivers, adjustable crossovers, and woofers to recreate a refined 3-way sound experience that matches their home speakers. A classic woofer with a twist The 6-1/2" woofer uses Focal's classic "W" sandwich cone design for incredibly accurate audio reproduction. The light foam core is sandwiched between the nimble aramid fiber and fiberglass layers, so the woofer can demonstrate the control needed to play delicate classical passages, yet handle the power needed to drive your bass-heavy tracks with authority. Focal adds a Tuned Mass Damper (TMD®) rubber surround which minimizes harmonic distortion for the cleanest midrange possible. The 3" driver in this 3-way system uses the same sandwich cone to deliver all the midrange details, as well as an aluminum phase plug for extended frequency response. The two included Focal crossovers provide five level and crossover slope settings to dial in the sound in your vehicle. A responsive tweeter Focal employs a unique 1-1/8" aramid fiber tweeter with an "M"-shaped inverted dome design that disperses the highs with remarkable precision, all the way up to 22,000 Hz. The K2 Power crossovers use hand-made components to deliver an ideal blend of the highs and lows for a dynamic stereo image. Five settings for tweeter, midrange, and woofer control let you dial in the sound to your car's environment. Product highlights: component speaker system includes two 6-1/2" woofers, two 3" midrange drivers, 2 tweeters, 2 external crossovers, and hardware K2 aramid fiber sandwich cone for woofer and midrange driver 3" midrange driver with aluminum phase plug Tuned Mass Damper (TMD®) rubber surround 1-1/8" FRAK "M"-shaped inverted-dome tweeter 2-way external crossover with 5 settings for levels and crossover slopes 4-ohm impedance handles up to 120 watts RMS (240 watts peak power) frequency response: 45-22,000 Hz sensitivity: 93 dB at 2.83V woofer mounting depth: 3" flush-mount brackets, angled surface-mount brackets, and aluminum grilles included warranty: 1 year MFR # ES165KX3E Item # 091ES16X3E What's in the box: Two woofers Focal owner's manual Two midrange Two inverted dome tweeters 2 Tweeter flush mount rings 2 Tweeter angled surface mount cups 2 Midrange/Tweeter surface mount housings 2 Crossover networks 2 Woofer grilles 2 Woofer grille mounting rings 2 Midrange grilles 2 Midrange grille mounting rings 2 Woofer mounting gaskets 2 Midrange mouting gaskets 16 Speed clips Eight 1" Screws Two 3/4" Screws Eight 5/8" Screws (Black) Two 5/8" Screws (Silver) Two M3x8mm Machine screws Quick start guide 2 Focal window stickers Features & specs General Speaker Size 6 1/2 Design 3-way Tweeter Design M-Shaped Inverted Dome Impedance (Ohms) 4 Tweeter Composition Aluminum Woofer Composition Aramid Fiber/Glass/Kevlar Woofer Surround Butyl Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) 89 Sensitivity at 2.83 volts 93 Frequency Response 45 - 22k Hz Minimum RMS Wattage --- Maximum RMS Wattage 120 Peak Power Handling (Watts) 240 Top-mount Depth (Inches) 3 Bottom-mount Depth (Inches) 3 1/4 Cutout Diameter or Length (inches) 5 5/8 Mounting Height (Inches) 0.4 Frame Width 6.495 Frame Length 6.495

Meticulous design and construction Handmade in France, the Elite K2 Power Series ES 165 KX2E component system is the culmination of Focal's passion for perfect sound. Focal's sound gurus engaged in intensive listening sessions designing this line of speakers so that you experience uncanny realism, sweeping dynamics, and breathtaking depth in your music. The system's 2-ohm impedance extracts maximum power from your amp so you'll get more punch from your system. The K2 woofer's beefy magnet enables it to handle and control gobs of power. A classic woofer with a twist The 6-1/2" woofer uses Focal's classic "W" sandwich cone design for incredibly accurate audio reproduction. The light foam core is sandwiched between the nimble aramid fiber and fiberglass layers, so the woofer can demonstrate the control needed to play delicate classical passages, yet handle the power needed to drive your bass-heavy tracks with authority. Focal adds a Tuned Mass Damper (TMD®) butyl rubber surround which minimizes harmonic distortion for the cleanest midrange possible. Focal also improves the woofer's range by incorporating an aluminum phase plug in the woofer for extended frequency response. A super-responsive tweeter Focal's FRAK tweeter employs a unique "M"-shaped inverted dome design that disperses the highs with remarkable precision, all the way up to 32,000 Hz. The tweeter construction combines aluminum and magnesium to keep it ultra-light and superbly accurate. The K2 Power crossovers use hand-made components developed by Focal to deliver an ideal blend of the highs and lows for a dynamic stereo image. They also include controls for a treble boost, a 3-level bass setting, and two crossover slope adjustments — all so you can dial in the sound to your car's environment. Product highlights: component speaker system includes two 6-1/2" woofers, 2 tweeters, 2 external crossovers, and hardware K2 aramid fiber sandwich woofer cone Tuned Mass Damper (TMD®) butyl rubber surround FRAK "M"-shaped inverted-dome tweeter made of aramid fiber 2-way external crossover with tweeter, woofer, and crossover slope settings 2-ohm impedance power handling: 120 watts RMS (240 watts peak power) frequency response: 55-32,000 Hz sensitivity: 92.5 dB at 2.83V woofer top mounting depth: 3.00" woofer and tweeter grilles included flush- and surface-mount tweeter brackets included warranty: 1 year MFR # ES165KX2E Item # 091ES16X2E What's in the box: Two woofers Focal owner's manual Two inverted dome tweeters 2 Crossovers 2 Tweeter flush mount rings 2 Tweeter angled surface mount cups 2 Tweeter grilles (installed) 2 Woofer grilles 2 Woofer grille mounting rings 2 Woofer gaskets 8 Speed clips Four 3/4" Screws Eight 1-1/8" Screws Quick start guide 2 Focal window stickers Features & specs General Speaker Size 6 1/2 Design 2-way Tweeter Design M-Shaped Inverted Dome Impedance (Ohms) 2 Tweeter Composition Aluminum Woofer Composition Aramid Fiber/Glass/Kevlar Woofer Surround Butyl Rubber Parts Warranty 1 Year Labor Warranty 1 Year Specifications Sensitivity (1W at 1 meter) 89.5 Sensitivity at 2.83 volts 92.5 Frequency Response 55 - 22k Hz Minimum RMS Wattage --- Maximum RMS Wattage 120 Peak Power Handling (Watts) 240 Top-mount Depth (Inches) 3 Bottom-mount Depth (Inches) 3 3/16 Cutout Diameter or Length (inches) 5 5/8 Mounting Height (Inches) 0.41 Frame Width 6.49 Frame Length 6.49
